STG50228 Starter Motor 410-54062 31100-44D10 31100-44D20 for Arctic Cat 400 500 650 Prowler Suzuki 500 QuadRunner 12V 1.2kW 9T CW Replacement

3 Reviews

Add Your Review

US$76.00

ITEMNO： STG50228

IN STOCK

BUY NOW ADD TO CART

Good Packaging

Safe Payment

100k+ Customers Top Choice

1 Year Warranty

90-Day Return

24/7 Service

TAGS：

Product Details Product Highlights Shipping

PRODUCT DETAILS

STG50228 Starter Motor 410-54062 31100-44D10 31100-44D20 for Arctic Cat 400 500 650 Prowler Suzuki 500 QuadRunner 12V 1.2kW 9T CW Replacement

Part Numbers

Arctic Cat: 0825-001, 0825-012, 0825-014, 3545-012, 3545-015, 3545-024
Suzuki: 31100-44D10, 31100-44D20, 31100-44D21
Arrowhead: 410-54062

Product Description

The STG50228 Starter Motor is an aftermarket replacement starter designed for selected Arctic Cat ATVs and Prowler utility vehicles, as well as compatible Suzuki QuadRunner, QuadMaster, and Vinson models.

Cross-referenced to Arctic Cat part numbers 0825-001 and 3545-012 and Suzuki part number 31100-44D10, this starter operates on a 12V electrical system and features a 9-tooth pinion with clockwise rotation. It is designed for compatible 400cc, 500cc, and 650cc ATV and utility vehicle applications.

Before ordering, verify the original starter part number, vehicle model year, mounting dimensions, and electrical connections to ensure correct fitment.

Product Specifications

Specification	Details
Product Type	ATV / UTV Starter Motor
SKU / Model	STG50228
Main Aftermarket Reference	410-54062
Arctic Cat References	0825-001, 0825-012, 0825-014
Suzuki References	31100-44D10, 31100-44D20, 31100-44D21
Voltage	12V
Power	1.2kW
Pinion Teeth	9T
Rotation	Clockwise (CW)
O-Ring Diameter	40mm
Mounting Bolt Center Distance	88mm
Estimated Net Weight	1.8kg
Condition	Aftermarket replacement

OEM / Cross Reference Table

Brand	Part Number
Arctic Cat	0825-001, 0825-012, 0825-014, 3545-012, 3545-015, 3545-024
Suzuki	31100-44D10, 31100-44D20, 31100-44D21
Arrowhead	410-54062
EMS	AC-8, AC-8N, SA-106N
J&N	410-54062
Lester	18796, 19088
Minnpar	57-2735
Piaggio	629874
PIC	191-482, 191-482A, 191-482B, 191-542, 191-557, 191-558
Stockers Starters	SA-106
Tucker Rocky	464101, 495772, 49-5772
Wilson Small Engine	71-26-18796
STG	STG50228

Compatible Applications

MAKE	TYPE	MODEL	YEAR	ENGINE
ARCTIC CAT	ATV	400 2X4	1998	376cc
ARCTIC CAT	ATV	400 2X4	1999	376cc
ARCTIC CAT	ATV	400 2X4	2000	376cc
ARCTIC CAT	ATV	400 2X4	2001	376cc
ARCTIC CAT	ATV	400 2X4	2002	376cc
ARCTIC CAT	ATV	400 4X4	1998	376cc
ARCTIC CAT	ATV	400 4X4	1999	376cc
ARCTIC CAT	ATV	400 4X4	2000	376cc
ARCTIC CAT	ATV	400 4X4	2001	376cc
ARCTIC CAT	ATV	400 4X4	2002	376cc
ARCTIC CAT	ATV	500 4X4 Automatic	2000	493cc
ARCTIC CAT	ATV	500 4X4 Automatic	2001	493cc
ARCTIC CAT	ATV	500 4X4 Automatic	2002	493cc
ARCTIC CAT	ATV	500 4X4 Automatic	2003	493cc
ARCTIC CAT	ATV	500 4X4 Automatic	2004	493cc
ARCTIC CAT	ATV	500 4X4 Automatic	2005	493cc
ARCTIC CAT	ATV	500 4X4 Automatic	2006	493cc
ARCTIC CAT	ATV	500 4X4 Automatic	2007	493cc
ARCTIC CAT	ATV	500 4X4 Automatic	2008	493cc
ARCTIC CAT	ATV	500 4X4 Automatic	2009	493cc
ARCTIC CAT	ATV	500 4X4 Manual	2001	493cc
ARCTIC CAT	ATV	500 4X4 Manual	2002	493cc
ARCTIC CAT	ATV	500 4X4 Manual	2003	493cc
ARCTIC CAT	ATV	500 4X4 Manual	2004	493cc
ARCTIC CAT	ATV	500 4X4 Manual	2005	493cc
ARCTIC CAT	ATV	500 4X4 Manual	2006	493cc
ARCTIC CAT	ATV	500 4X4 Manual	2007	493cc
ARCTIC CAT	ATV	500 4X4 Manual	2008	493cc
ARCTIC CAT	ATV	500 4X4 Manual	2009	493cc
ARCTIC CAT	ATV	500 FIS	2002	493cc
ARCTIC CAT	ATV	500 FIS	2003	493cc
ARCTIC CAT	ATV	500 FIS	2004	493cc
ARCTIC CAT	ATV	500 FIS	2005	493cc
ARCTIC CAT	ATV	500 FIS	2006	493cc
ARCTIC CAT	ATV	500 FIS	2007	493cc
ARCTIC CAT	ATV	500 FIS	2008	493cc
ARCTIC CAT	ATV	500 TBX	2002	493cc
ARCTIC CAT	ATV	500 TBX	2003	493cc
ARCTIC CAT	ATV	500 TBX	2004	493cc
ARCTIC CAT	ATV	500 TBX	2005	493cc
ARCTIC CAT	ATV	500 TBX	2006	493cc
ARCTIC CAT	ATV	500 TRV	2003	493cc
ARCTIC CAT	ATV	500 TRV	2004	493cc
ARCTIC CAT	ATV	500 TRV	2005	493cc
ARCTIC CAT	ATV	500 TRV	2006	493cc
ARCTIC CAT	ATV	500 TRV	2007	493cc
ARCTIC CAT	ATV	500 TRV	2008	493cc
ARCTIC CAT	ATV	650 4X4 Automatic	2007	641cc
ARCTIC CAT	ATV	650 H1 4X4	2005	641cc
ARCTIC CAT	ATV	650 H1 4X4	2006	641cc
ARCTIC CAT	ATV	650 H1 4x4 FIS	2007	641cc
ARCTIC CAT	ATV	650 H1 4x4 TBX	2007	641cc
ARCTIC CAT	ATV	650 H1 4x4 TRV	2007	641cc
ARCTIC CAT	ATV	650 V-2 4x4 FIS	2006	641cc
ARCTIC CAT	ATV	650 V-2 4x4 FIS TS	2006	633cc
ARCTIC CAT	UTV	Prowler 650	2007	641cc
ARCTIC CAT	UTV	Prowler 650 XT	2006	641cc
ARCTIC CAT	UTV	Prowler 650 XT	2007	641cc
MASSEY FERGUSON	ATV	400 4X4	2000	376cc
MASSEY FERGUSON	ATV	400 4X4	2001	376cc
MASSEY FERGUSON	ATV	400 4X4	2002	376cc
MASSEY FERGUSON	ATV	500 4X4	2002	493cc
MASSEY FERGUSON	ATV	500 4X4	2003	493cc
MASSEY FERGUSON	ATV	500 4X4	2004	493cc
MASSEY FERGUSON	ATV	500 4X4	2005	493cc
MASSEY FERGUSON	ATV	500 4X4	2006	493cc
MASSEY FERGUSON	ATV	500 4X4	2007	493cc
MASSEY FERGUSON	ATV	650 4X4	2005	641cc
MASSEY FERGUSON	ATV	650 4X4	2006	641cc
MASSEY FERGUSON	ATV	650 4X4	2007	641cc
SUZUKI	ATV	LT-A500F QuadMaster	2000	500cc
SUZUKI	ATV	LT-A500F QuadMaster	2001	500cc
SUZUKI	ATV	LT-A500F Vinson 4WD	2002	493cc
SUZUKI	ATV	LT-A500F Vinson 4WD	2003	493cc
SUZUKI	ATV	LT-A500F Vinson 4WD	2004	493cc
SUZUKI	ATV	LT-A500F Vinson 4WD	2005	493cc
SUZUKI	ATV	LT-A500F Vinson 4WD	2006	493cc
SUZUKI	ATV	LT-A500F Vinson 4WD	2007	493cc
SUZUKI	ATV	LT-A500FB Vinson 4WD	2004	493cc
SUZUKI	ATV	LT-A500FB Vinson 4WD	2005	493cc
SUZUKI	ATV	LT-A500FB Vinson 4WD	2006	493cc
SUZUKI	ATV	LT-A500FB Vinson 4WD	2007	493cc
SUZUKI	ATV	LT-A500FC Vinson 4WD	2004	493cc
SUZUKI	ATV	LT-A500FC Vinson 4WD	2005	493cc
SUZUKI	ATV	LT-A500FC Vinson 4WD	2006	493cc
SUZUKI	ATV	LT-A500FC Vinson 4WD	2007	493cc
SUZUKI	ATV	LT-F500F Quadrunner	2000	500cc
SUZUKI	ATV	LT-F500F Quadrunner	2001	500cc
SUZUKI	ATV	LT-F500F Quadrunner	2002	500cc
SUZUKI	ATV	LT-F500F Vinson 4WD	2003	493cc
SUZUKI	ATV	LT-F500F Vinson 4WD	2004	493cc
SUZUKI	ATV	LT-F500F Vinson 4WD	2005	493cc
SUZUKI	ATV	LT-F500F Vinson 4WD	2006	493cc
SUZUKI	ATV	LT-F500F Vinson 4WD	2007	493cc
SUZUKI	ATV	LT-F500FC Vinson 4WD	2004	493cc
SUZUKI	ATV	LT-F500FC Vinson 4WD	2005	493cc
SUZUKI	ATV	LT-F500FC Vinson 4WD	2006	493cc
SUZUKI	ATV	LT-F500FC Vinson 4WD	2007	493cc
SUZUKI	Motorcycles \\ Off-Road	DR650SE	1998	644cc

PRODUCT HIGHLIGHTS

Product Highlights

Reliable ATV Starting	12V Electrical System	Multi-Brand Compatibility
1.2kW reference rating with a 9-tooth pinion	Designed for compatible 12V systems with clockwise rotation	Cross-referenced for selected Arctic Cat and Suzuki ATV / UTV models
