STG50251 Starter Motor F2TU-11000-BA F2TZ-11002-B F7PU-11000-GA for Ford E-Series Vans and Trucks 12V 10T 1.5kW CW PMGR Replacement

3 Reviews

Add Your Review

US$118.00

ITEMNO： STG50251

IN STOCK
BUY NOW ADD TO CART

Good Packaging

Safe Payment

100k+ Customers Top Choice

1 Year Warranty

90-Day Return

24/7 Service

TAGS：

Product Details Product Highlights Shipping

  • PRODUCT DETAILS

    STG50251 Starter Motor F2TU-11000-BA F2TZ-11002-B F7PU-11000-GA for Ford E-Series Vans and Trucks 12V 10T 1.5kW CW PMGR Replacement

    Part Numbers

    AC DELCO336-1168
    ACECM-7011, CM-7111
    ARROWHEAD (OLD)SFD0051
    ARROWHEADSFD0030
    BARSANCO520-3226, 520-3247
    CARGO112595, 113221
    DENSO FIRST TIME FIT280-5116
    DIXIES-2071
    DIXIE NEWS-2071N
    FAMILYFORD PMGR
    FORDF2TU-11000-BA, F2TZ-11002-B, F7PU-11000-GA, F7PZ-11002-GA
    J & N410-14035
    LESTER3226, 3247
    MINNPAR57-2393
    MOTORCRAFTSA-794, SA-852
    NAPA POWER NEW4N-9260
    NAPA POWER PREMIUM PLUS244-9260
    NAPA POWER SUPREME44-9260
    NSASTR-2830
    PIC150-325, 150-325A
    RCPST-794
    REMY LIGHT DUTY25523, 27003
    REMY LIGHT DUTY NEW97113
    USA INDUSTRIES3226
    WAI (OLD)2-1569-FD
    WAI2-1883-FD, 2-1883-FD-1
    WAI SALES50-230
    WILSON91-02-5862
    WILSON NEW91-02-5862, 91-02-5862N

    Product Description

    The STG50251 Starter Motor is a brand-new aftermarket replacement designed for compatible Ford truck and van applications. Operating at 12 volts with 1.5kW power output, this starter features a 10-tooth pinion, clockwise (CW) rotation, and a Permanent Magnet Gear Reduction (PMGR) design to provide dependable engine-cranking performance.

    This starter is listed for select Ford E-Series vans equipped with the 7.5L (460 cu. in.) V8 engine for the 1992 and 1993 model years. The supplied application notes also reference Ford trucks and vans with automatic transmissions from 1992 through 1997; however, the detailed fitment table specifically identifies only the E-Series van applications for 1992 and 1993.

    The unit cross-references multiple Ford, Motorcraft, Delco, Arrowhead, Lester, and other aftermarket part numbers, including Ford F2TU-11000-BA, F2TZ-11002-B, and F7PU-11000-GA. Before ordering, compare the original starter number, mounting configuration, electrical terminals, pinion gear, and transmission application to confirm compatibility.

    Product Specs

    Item ConditionAftermarket Part
    Unit TypeStarter
    Voltage12
    RotationCW
    Teeth10
    KW1.5
    Starter TypePMGR
    FitsFORD TRUCKS & VANS w/AT 1992-97

         Vehicle Fitment

    MAKETYPE MODEL YEAR ENGINE
    FORDAuto and Light TruckE-SERIES VANS19927.5L(460) V8
    FORDAuto and Light TruckE-SERIES VANS19937.5L(460) V8
    FORDAuto and Light TruckE-SERIES VANS19947.5L(460) V8
    FORDAuto and Light TruckE-SERIES VANS19957.5L(460) V8
    FORDAuto and Light TruckE-SERIES VANS19967.5L(460) V8
    FORDAuto and Light TruckF-100 to F-350 PICKUP (1948-98)19927.5L(460) V8
    FORDAuto and Light TruckF-100 to F-350 PICKUP (1948-98)19937.5L(460) V8
    FORDAuto and Light TruckF-100 to F-350 PICKUP (1948-98)19947.5L(460) V8
    FORDAuto and Light TruckF-100 to F-350 PICKUP (1948-98)19957.5L(460) V8
    FORDAuto and Light TruckF-100 to F-350 PICKUP (1948-98)19967.5L(460) V8
    FORDAuto and Light TruckF-100 to F-350 PICKUP (1948-98)19977.5L(460) V8

    Packaging Information

    ItemDetails
    ProductSTG50251 Starter Motor
    Estimated Net Weight3.2 kg
    Estimated Gross Weight3.8 kg
    Estimated Package Dimensions25 × 18 × 16 cm
    PackagingProtective carton with internal cushioning


  • PRODUCT HIGHLIGHTS

    Product Highlights

    FeatureDescriptionBenefit
    PMGR ConstructionPermanent Magnet Gear Reduction starter designProvides a compact gear-reduction starter configuration
    1.5kW Cranking Output12V operation with 10-tooth pinionSupports engine starting in compatible applications
    Multiple Cross ReferencesFord, Motorcraft, Delco, Arrowhead, and Lester numbersHelps buyers match the replacement to the original part

  • SHIPPING

    Item Details
    Processing Time Orders are processed within 1-3 business days after payment confirmation
    Shipping Methods DHL/UPS/ FedEx/ TNT/ Air Freight/ Sea Freight
    Estimated Delivery Time Express shipping: 3-7 business days, depending on destination
    Packaging Export-standard cartons with protective inner packing
    Tracking Tracking number will be provided once the order is shipped
    Shipping Cost Calculated based on weight, dimensions, and destination
