STG52038 Starter Motor SND0562 428000-5190 410-52167 for Kenworth C500 T2000 T600 T800 W900 and Peterbilt 357 | 12V 5.0kW 10T CW OSGR Replacement

3 Reviews

Add Your Review

US$158.00

ITEMNO： STG52038

IN STOCK
BUY NOW ADD TO CART

Good Packaging

Safe Payment

100k+ Customers Top Choice

1 Year Warranty

90-Day Return

24/7 Service

TAGS：

Product Details Product Highlights Shipping

  • PRODUCT DETAILS

    STG52038 Starter Motor SND0562 428000-5190 410-52167 for Kenworth C500 T2000 T600 T800 W900 and Peterbilt 357 | 12V 5.0kW 10T CW OSGR Replacement

    Part Numbers

    ARROWHEADSND0562, NDTG428000-5190
    DENSO428000-5190, TG428000-5190
    J & N410-52167
    LESTER19505

    Product Description

    The STG52038 Starter Motor is a brand-new aftermarket replacement starter designed for selected Kenworth and Peterbilt medium- and heavy-duty truck applications. Operating at 12V with a rated output of 5.0 kW, it is designed to deliver the cranking power required by compatible heavy-duty diesel engine systems.

    This starter features an offset gear reduction (OSGR) design, clockwise (CW) rotation, and a 10-tooth pinion gear. It cross-references Arrowhead SND0562, Denso 428000-5190, J & N 410-52167, and Lester 19505, helping fleet operators, repair shops, and parts distributors identify a potential replacement for the original starter.

    The supplied application information lists Kenworth C500 trucks equipped with Cummins ISX engines for model years 2000–2002. The product title also identifies Kenworth T2000, T600, T800, and W900, as well as Peterbilt 357, as potential applications. Since complete year and engine fitment details were not supplied for all these models, verify the original starter number, engine configuration, mounting pattern, electrical connections, and pinion specifications before ordering.

    Product Specs

    Item ConditionAftermarket Part
    Unit TypeStarter
    Voltage12
    RotationCW
    Teeth10
    KW5.0
    Starter TypeOSGR



    Compatible Applications



    MAKETYPE MODEL YEAR ENGINE
    KENWORTHMedium & Heavy-Duty TruckC5002000Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckC5002001Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckC5002002Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckC5002003Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckC5002004Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckC5002005Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckC5002006Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckC5002007Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckT20001997Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckT20001998Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckT20001999Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckT20002000Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckT20002001Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckT20002002Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckT20002003Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckT20002004Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckT20002005Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckT20002006Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckT20002007Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckT600 / T8002000Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckT600 / T8002001Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckT600 / T8002002Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckT600 / T8002003Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckT600 / T8002004Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckT600 / T8002005Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckT600 / T8002006Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckT600 / T8002007Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckW9001999Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckW9002000Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckW9002001Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckW9002002Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckW9002003Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckW9002004Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckW9002005Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckW9002006Cummins ISX
    KENWORTHMedium & Heavy-Duty TruckW9002007Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3571998Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3571999Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3572000Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3572001Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3572002Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3572003Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3572004Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3572005Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3572006Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3572007Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3781997Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3781998Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3781999Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3782000Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3782001Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3782002Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3782003Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3782004Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3782005Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3782006Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3782007Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3791997Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3791998Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3791999Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3792000Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3792001Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3792002Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3792003Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3792004Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3792005Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3792006Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3792007Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3862006Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3862007Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3872000Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3872001Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3872002Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3872003Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3872004Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3872005Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3872006Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3872007Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3892004Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3892005Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3892006Cummins ISX
    PETERBILTMedium & Heavy-Duty Truck3892007Cummins ISX

    Packaging Information

    ItemDetails
    Package Contents1 × Starter Motor
    Estimated Net Weight9.0 kg
    Estimated Packaging Weight1.0 kg
    Estimated Gross Weight10.0 kg
    Estimated Package Dimensions35 × 25 × 22 cm
    Packaging TypeProtective Carton
