STG52285 Starter Motor 50496200 50496201 11.130.922 AZE2605 IS1149 MS140 LRS02760 for BOMAG BW65H Hatz 1D41 1D42 Engines 12V 2kW 9T CW PMGR Replacement

3 Reviews

Add Your Review

US$128.00

ITEMNO： STG52285

IN STOCK

BUY NOW ADD TO CART

Good Packaging

Safe Payment

100k+ Customers Top Choice

1 Year Warranty

90-Day Return

24/7 Service

TAGS：

Product Details Product Highlights Shipping

PRODUCT DETAILS

STG52285 Starter Motor 50496200 50496201 11.130.922 AZE2605 IS1149 MS140 LRS02760 for BOMAG BW65H Hatz 1D41 1D42 Engines 12V 2kW 9T CW PMGR Replacement

Part Numbers

Hatz: 50496200 / 50496201
Mahle: 11.130.922 / 11.131.527 / AZE2605 / IS1149 / MS140
Letrika / Iskra: 11.130.922 / AZE2605 / IS1149
Lucas: LRS02760
Arrowhead: IS1149 / SIA0021
J&N: 410-29057
Lester: 19665 / 30253

Product Description

The STG52285 Starter Motor is a brand-new aftermarket replacement designed for compatible Hatz diesel engines and BOMAG light compaction equipment. It cross-references Hatz OEM part numbers 50496200 and 50496201, along with Mahle, Letrika/Iskra, and Lucas starter references.

Featuring a 12V electrical system, 2kW output, 9-tooth pinion, clockwise rotation, and permanent magnet gear reduction (PMGR) construction, this starter is designed to provide dependable cranking performance for compatible compactors and industrial diesel engines.

Before ordering, compare the original starter part number, mounting dimensions, pinion gear, and electrical connections to confirm compatibility.

Product Specifications

Specification	Details
Product SKU	STG52285
Product Type	Starter Motor
Condition	Brand New Aftermarket
Voltage	12V
Power Output	2kW
Number of Teeth	9T
Rotation	Clockwise (CW)
Starter Type	PMGR (Permanent Magnet Gear Reduction)
Pinion Gear Outside Diameter	29mm
Overall Length	187.5mm
Mounting	2 mounting holes
Mounting Hole Diameter	12.7mm
Battery / Motor Stud Thread	M8 × 1.25
Compatible Engine Type	Hatz air-cooled diesel engines
Estimated Net Weight	3.5kg

OEM / Cross Reference Table

Brand	OEM / Cross Reference Numbers
Hatz	50496200, 50496201
Mahle	11.130.922, 11.131.527, AZE2605, IS1149, MS140
Letrika / Iskra	11.130.922, AZE2605, IS1149
Lucas	LRS02760
Arrowhead	IS1149, SIA0021
J&N	410-29057
Lester	19665, 30253

Compatible Applications

Equipment / Engine Model	Application Details
BOMAG BW65H	Vibratory drum roller, 0.5L engine
Ahlmann AR65	Compactor, 0.4L engine
Hatz 1D41	Air-cooled diesel engine, 0.4L
Hatz 1D41S	Air-cooled diesel engine, 0.4L
Hatz 1D42	Air-cooled diesel engine, 0.5L
Hatz 1D42C	Air-cooled diesel engine, 0.5L
Hatz 1D42S	Air-cooled diesel engine, 0.5L
