STG52289 Starter SBO0373 0-001-121-408 for Audi Seat Skoda Volkswagen | 12V 1.1KW 10T CCW PMGR Replacement

3 Reviews

Add Your Review

US$126.00

ITEMNO： STG52289

IN STOCK
BUY NOW ADD TO CART

Good Packaging

Safe Payment

100k+ Customers Top Choice

1 Year Warranty

90-Day Return

24/7 Service

TAGS：

Product Details Product Highlights Shipping

  • PRODUCT DETAILS

    STG52289 Starter SBO0373 0-001-121-408 for Audi Seat Skoda Volkswagen | 12V 1.1KW 10T CCW PMGR Replacement

    Part Numbers

    Bosch: 0 001 121 408 / 0 001 121 409 / 0 986 020 240
    Bosch Trade Numbers: RF70-M25 12V (L) / SR9513N
    Volkswagen / Audi: 02Z 911 023 E / 02Z 911 023 G / 02Z 911 024 P
    Delco Remy: DRT0240

    Product Description

    STG52289 Starter SBO0373 is a new aftermarket replacement starter designed for applications using Bosch 0 001 121 408.

    With a 12V, 1.1KW, 10-tooth, CCW PMGR configuration, this starter is designed to provide reliable engine cranking performance for selected European passenger vehicle applications. Catalog data confirms the original Bosch unit uses a 10-tooth pinion, anticlockwise rotation, 3 mounting holes, and a 76.2 mm flange diameter.

    The starter is associated with Audi, Seat, Skoda, and Volkswagen applications and cross-references including Bosch RF70-M25 12V (L), SR9513N and OE numbers from the 02Z 911 023 / 02Z 911 024 series.

    Product Specifications

    PropertyValue
    Product ModelSTG52289
    Part NumberSBO0373 / 0-001-121-408
    Unit TypeStarter Motor
    Voltage12V
    Power Output1.1KW
    Number of Teeth10T
    Starter TypePMGR
    RotationCCW
    Mounting Holes3
    Flange Diameter76.2 mm
    Pinion Rest Position52.5 mm
    Mounting Angle42°
    ConditionNew Aftermarket
    ApplicationAutomotive Starter
    Weight3.6kg

    The 12V, 1.1KW, 10T, CCW, 3-hole and 76.2 mm flange specifications are supported by Bosch-compatible catalog data.

    OEM / Cross Reference Table

    BrandPart Number
    BOSCH0 001 121 408 / 0 001 121 409 / 0 986 020 240
    BOSCH TRADE NUMBERSRF70-M25 12V (L) / SR9513N
    VOLKSWAGEN / AUDI02Z 911 023 E / 02Z 911 023 G / 02Z 911 024 P
    DELCO REMYDRT0240
    HELLA8EA 738 157-001
    LETRIKA / ISKRAIS9431
    LUCAS ELECTRICALLRS01676 / LRS1676
    MAGNETI MARELLIMSN2102
    HC-PARTSCS1294
    VALEO458213

    Compatible Applications

    Vehicle Brand / ModelCompatible Applications
    Audi A1Selected 1.4L–2.0L applications
    Audi A3A3 8P / A3 8P1 selected applications
    Volkswagen GolfGolf V / Golf VI selected applications
    Volkswagen Golf PlusSelected applications
    Volkswagen PassatPassat B6 / B7 selected applications
    Volkswagen PoloPolo 9N selected applications
    Volkswagen TouranTouran 1T2 / 1T3 selected applications
    Volkswagen T5T5 Van / T5 Multivan selected applications
    Volkswagen SciroccoScirocco III selected applications
    SEAT IbizaIbiza 6L1 selected applications
    SEAT LeonLeon 1P selected applications
    Skoda OctaviaOctavia II / 1Z3 / 1Z5 selected applications
