STG52652 Starter 410-12736 410-12487 10461195 10479074 10479101 for Caterpillar 5130B Mining D10R D11RCD Tractors

Part Numbers

ARROWHEAD: 410-12487, 410-12736
CATERPILLAR: 10R0937, 123-8686
J & N: 410-12736
RPM INDUSTRIES: 100385
REMY: 10461195, 10479074, 10479101

Product Description

This premium aftermarket 24V 9KW Starter Motor is designed as a direct replacement for Caterpillar 5130B Mining, D10R, D11R, D11RCD, D9R, and D9RLRC applications. Built on the Delco 50MT Prelub family with Direct Drive (DD) design, 11-tooth pinion gear, and clockwise rotation, it delivers fast, reliable engine starting and dependable performance in demanding mining and heavy equipment applications.

Assembled by J&N in Cincinnati, Ohio, USA of all new components. Prelub assembly on CE housing.

This starter replaces OE part numbers 410-12487, 410-12736 (Arrowhead), 10R0937, 123-8686 (Caterpillar), 410-12736 (J & N), 100385 (RPM Industries), and 10461195, 10479074, 10479101 (Remy).

• 24V starter motor

• 9KW power output

• Direct Drive (DD) design

• 11-tooth pinion gear

• Clockwise rotation

• Delco 50MT Prelub family

• Semi solid link

• Prelub assembly on CE housing

• Assembled in USA of all new components

• Premium quality type

• Aftermarket replacement part

• Approx. 36 kg

Specifications

Item Condition: Aftermarket Part
Description: Starter
Critical Note: Assembled by J & N in Cincinnati, Ohio, USA of All New Components
Family: Delco 50MT Prelub
Volt: 24V
Power: 9 KW
HP: 12.069
Quality Type: Premium
Rotation Direction: Clockwise
Electric Starter Type: Direct Drive (DD)
Number Of Teeth: 11
Gear OD: 2.209" / 56.100mm
Solenoid Position: 52 / 52 °
Mount Hole ID 1: 16.500mm
Mount Hole 1 Type: Unthreaded
Mount Hole 2 Type: Unthreaded
Mount Hole ID 3: 16.500mm
Mount Hole 3 Type: Unthreaded
Semi Solid Link: True
Note: Prelub Assembly on CE Housing
Weight: 36KG

Fitment

Caterpillar – 5130B Mining – Cat. 3508
Caterpillar – D10R
Caterpillar – D11R
Caterpillar – D11RCD
Caterpillar – D9R
Caterpillar – D9RLRC

Compatible with equipment using 410-12736, 410-12487, 10R0937, 123-8686, or 100385 starter motor part numbers.
