STG53143 Starter MAH-MS430 11.131.108 11.131.384 11.131.751 11.131.833 11.132.227 AZE4169 AZE4185 AZE4261 for John Deere 45 Self Propelled 4039DFM – 12V 3.0KW 10T
Part Numbers
ARROWHEAD: IMI25208-002, MS430, SBO0290, SIA0016, V438012
ATLANTIC QUALITY PARTS: 1400-0121
BOSCH: 0001223502, 0-001-223-502, 0-001-358-041, 0986022520, SR901X
J & N: 410-16003, 410-29059
JOHN DEERE: RE501347, RE501680, RE501693, RE501713, RE502156, RE502196, RE516455, RE516455A, RE519568, RE551444, RE60641, RE62916, RE63010, SE501411, SE501869
LESTER: 16563, 17086, 18476, 18526
LETRIKA / ISKRA: 11.131.108, 11.131.384, 11.131.751, 11.131.833, 11.132.227, AZE4169, AZE4185, AZE4261, AZE4534, AZE4589, IS 1059
LUCAS ELECTRIC: LRS01089, LRS03792
MAHLE: 11.131.108, 11.131.384, 11.131.751, 11.131.833, AZE4169, AZE4185, AZE4534, AZE4589, IS1059, MS430
PARIS RHONE: D7R14
VALEO: 187031, 438012, 455735, D7R14
Product Description
This premium aftermarket 12V 2.8KW Starter Motor is designed as a direct replacement for John Deere 45 Self Propelled and 4039DFM engine applications, as well as a wide range of agricultural and construction equipment. Built on the Letrika / MAHLE AZE45 family with Planetary Gear Reduction (PLGR) design, 10-tooth pinion gear, and clockwise rotation, it delivers fast, reliable engine starting and dependable performance in demanding applications.
This starter replaces OE part numbers IMI25208-002, MS430, SBO0290, SIA0016, V438012 (Arrowhead), 1400-0121 (Atlantic Quality Parts), 0001223502, 0-001-223-502, 0-001-358-041, 0986022520, SR901X (Bosch), 410-16003, 410-29059 (J & N), RE501347, RE501680, RE501693, RE501713, RE502156, RE502196, RE516455, RE516455A, RE519568, RE551444, RE60641, RE62916, RE63010, SE501411, SE501869 (John Deere), 16563, 17086, 18476, 18526 (Lester), 11.131.108, 11.131.384, 11.131.751, 11.131.833, 11.132.227, AZE4169, AZE4185, AZE4261, AZE4534, AZE4589, IS 1059 (Letrika / Iskra), LRS01089, LRS03792 (Lucas Electric), 11.131.108, 11.131.384, 11.131.751, 11.131.833, AZE4169, AZE4185, AZE4534, AZE4589, IS1059, MS430 (Mahle), D7R14 (Paris Rhone), and 187031, 438012, 455735, D7R14 (Valeo).
12V starter motor
2.8KW power output
10-tooth pinion gear
Planetary Gear Reduction (PLGR) design
Clockwise rotation
Letrika / MAHLE AZE45 family
Includes solenoid cover & plastic nut
Battery & motor studs M10-1.5 threaded
External thru bolts
Direct replacement for John Deere 45 Self Propelled / 4039DFM
Aftermarket replacement part
Approx. 7.6 kg
Specifications
Item Condition: Aftermarket Part
Description: Starter
Family: Letrika / MAHLE AZE45
Volt: 12V
Power: 2.800 KW
HP: 3.755
Condition: New
Rotation Direction: Clockwise
Electric Starter Type: Planetary Gear Reduction (PLGR)
Number Of Teeth: 10
Gear OD: 1.248" / 31.700mm
Mount Hole ID 1: 10.400mm
Mount Hole 1 Type: Unthreaded
Mount Hole 2 Type: Unthreaded
Includes: Solenoid Cover & Plastic Nut, Battery & Motor Studs M10-1.5 Threaded, External Thru Bolts
Weight: 7.6KG
Fitment
Bobcat – 975, 1075, 1080, 1080B (4-276 Diesel)
Clark – 975, 1075, 1080 (J. Deere 427)
Clark – UT40, UT60 (John Deere 3-16, 3-8, 4-21, 4-8)
John Deere – 45 Self Propelled
John Deere – 4039DFM (Code 3006)
John Deere – 1020, 1030, 1030OU, 1030VU, 1032, 1035, 1035EF, 1035EV, 1040, 1040V, 1042, 1052, 1055, 1065, 1068, 1072, 1075, 1120, 1130, 1133, 1140, 1140F, 1140V, 1144, 1155, 1157, 1158, 1165, 1166, 1169, 1174, 1175, 1177
John Deere – 135, 152, 180, 202, 219, 329 Diesel Engines
John Deere – 1520, 1530, 1550, 1630, 1630OU, 1630VU, 1635, 1635EF, 1635EV, 164, 1640, 1640F, 1745F, 1750, 1750V, 1830, 1840, 1840F, 1845F, 1850, 1850F, 1850V, 1950, 1950F, 2020, 2030, 2030OU, 2035, 2035EF, 2040, 2040F, 2040S, 2054, 210C, 2120, 2130, 2135, 2140, 2150, 2155, 2240, 2250, 2250F, 2254, 2255, 2270, 2280, 2320, 2345F, 2350, 2355, 2360
John Deere – 240, 240 Series II, 2420, 2440, 2450, 2450F, 250, 250 Series II, 2510, 2520, 2550, 2555, 260, 260 Series II, 2630, 2640, 2650, 2650F, 2750, 2755, 2840, 2850, 2855N, 2940, 2950, 2955
John Deere – 300, 300B, 300D, 301, 301A, 302, 302A, 303, 3030, 3040, 3050, 3055, 310, 3100, 310A, 310B, 310C, 310D, 3110, 3120, 3130, 3135, 3140, 3150, 3155, 315C, 315D, 3164, 3164D, 3200, 3210, 3255, 3300, 3310, 3340, 3350, 3400, 3410, 3430, 350C, 350D, 355, 355D, 3640, 3650, 3830, 3930
John Deere – 400, 400A, 400B, 400G, 401, 401A, 401B, 401C, 401D, 4039, 4039DFM (Code 3006), 4045, 4045DFM50 (Code 3008), 4045DFM70 (Code 3008), 4045TFM (Code 3006), 4045TFM75 (Code 3008), 410
Compatible with equipment using MS430, 11.131.108, AZE4169, RE501347, or SE501869 starter motor part numbers.
