STG53150 Starter 28100-23660-71 128000-0970 128000-0971 128000-0972 128000-0973 128000-0974 228000-3710 228000-3711 for Toyota Lift Truck 5FD-28 5FD-30 5FD-33 5FD-35 5FD-38

Part Numbers

ARROWHEAD: SND0418, ND280-7005
CARGO: 112036, 113238
DENSO: 128000-0970, 128000-0971, 128000-0972, 128000-0973, 128000-0974, 228000-3710, 228000-3711
HYSTER: 3049479
J & N: 410-52008
LESTER: 17311
TOYOTA: 28100-23660-71, 28100-40290, 28100-40290-71, 28100-40291, 28100-40291-71
UNIPOINT: STR-6073
WAI: 17311N, 2-2784-ND

Product Description

This premium aftermarket 12V 2.5KW Starter Motor is designed as a direct replacement for Toyota diesel lift trucks, including 5FD and 6FD series models. With OSGR design, 11-tooth pinion gear, and clockwise rotation, it delivers fast, reliable engine starting and dependable performance in demanding material handling applications.

This starter replaces OE part numbers SND0418, ND280-7005 (Arrowhead), 112036, 113238 (Cargo), 128000-0970, 128000-0971, 128000-0972, 128000-0973, 128000-0974, 228000-3710, 228000-3711 (Denso), 3049479 (Hyster), 410-52008 (J & N), 17311 (Lester), 28100-23660-71, 28100-40290, 28100-40290-71, 28100-40291, 28100-40291-71 (Toyota), STR-6073 (Unipoint), and 17311N, 2-2784-ND (WAI).

• 12V starter motor

• 2.5KW power output

• 11-tooth pinion gear

• OSGR design

• Clockwise rotation

• Fits Toyota diesel 6000LB lift truck

• Reliable starting performance

• Durable construction

• Aftermarket replacement part

• Approx. 9.3 kg

Specifications

Item Condition: Aftermarket Part
Unit Type: Starter
Voltage: 12V
Rotation: CW
Teeth: 11T
KW: 2.5
Starter Type: OSGR
Fits: Toyota Diesel 6000LB Lift Truck
Weight: 9.3KG

Fitment

Toyota – Lift Trucks 5FD-10 – 1986-1994 – 1DZ / 2J Engine
Toyota – Lift Trucks 5FD-14 – 1986-1994 – 1DZ / 2J Engine
Toyota – Lift Trucks 5FD-15 – 1986-1994 – 1DZ / 2J Engine
Toyota – Lift Trucks 5FD-18 – 1986-1994 – 1DZ / 2J Engine
Toyota – Lift Trucks 5FD-20 – 1986-1994 – 1DZ / 1Z / 2J Engine
Toyota – Lift Trucks 5FD-23 – 1986-1994 – 1DZ / 1Z / 2J Engine
Toyota – Lift Trucks 5FD-25 – 1986-1994 – 1DZ / 1Z / 2J Engine
Toyota – Lift Trucks 5FD-28 – 1986-1994 – 1Z Engine
Toyota – Lift Trucks 5FD-30 – 1986-1994 – 1Z Engine
Toyota – Lift Trucks 5FD-33 – 1988-1994 – 11Z Engine
Toyota – Lift Trucks 5FD-35 – 1988-1994 – 11Z Engine
Toyota – Lift Trucks 5FD-38 – 1988-1994 – 11Z Engine
Toyota – Lift Trucks 5FD-40 – 1988-1994 – 11Z Engine
Toyota – Lift Trucks 5FD-45 – 1988-1994 – 11Z Engine
Toyota – Lift Trucks 6FD-10 – 94-On – 1DZ Engine
Toyota – Lift Trucks 6FD-14 – 94-On – 1DZ Engine
Toyota – Lift Trucks 6FD-15 – 94-On – 1DZ Engine
Toyota – Lift Trucks 6FD-18 – 94-On – 1DZ Engine
Toyota – Lift Trucks 6FD-20 – 94-On – 1DZ / 2DZ Engine
Toyota – Lift Trucks 6FD-23 – 94-On – 1DZ / 2DZ Engine
Toyota – Lift Trucks 6FD-25 – 94-On – 1DZ / 2DZ Engine
Toyota – Lift Trucks 6FD-28 – 94-On – 2DZ Engine
Toyota – Lift Trucks 6FD-30 – 94-On – 2DZ Engine

Compatible with equipment using 28100-23660-71, 128000-0970, 228000-3710, or SND0418 starter motor part numbers.
