ATG10165 Alternator XR3U-10300-AA XR3U-10300-AB 8252 for Ford Mustang 4.6L V8 1999–2004 | 12V 105A CW Replacement-Products-TIANGUAN-Page 1

Home Products

ATG10165 Alternator XR3U-10300-AA XR3U-10300-AB 8252 for Ford Mustang 4.6L V8 1999–2004 | 12V 105A CW Replacement

3 Reviews

Add Your Review

US$128.00

ITEMNO： ATG10165

IN STOCK

BUY NOW ADD TO CART

Good Packaging

Safe Payment

100k+ Customers Top Choice

1 Year Warranty

90-Day Return

24/7 Service

TAGS：

Product Details Product Highlights Shipping

PRODUCT DETAILS

ATG10165 Alternator XR3U-10300-AA XR3U-10300-AB 8252 for Ford Mustang 4.6L V8 1999–2004 | 12V 105A CW Replacement

Part Numbers

ANDRE NIERMANN	28424
ARROWHEAD	AFD0059, 400-14040
BARSANCO	120-8252
CARGO	112954
DIXIE	A-290
DUBOIS	908252
FAMILY	6GIF
FORD	XR3U-10300-AA, XR3U-10300-AB, XR3U-10300-AC, XR3Z-10346-AA
J & N	400-14040
LESTER	8252
MINNPAR	47-1862
MOTORCRAFT	GL-424
NAPA POWER NEW	1N-3143
NAPA POWER PREMIUM PLUS	213-3143
NAPA POWER SUPREME	13-3143
NSA (OLD)	ALT-1606
PIC	250-283
RCP	41140
REGITAR-USA	A250-283N
REMY LIGHT DUTY	23688
REMY LIGHT DUTY NEW	92506
USA INDUSTRIES	8252
VISTEON	CY
WAI	1-2264-31FD, 8252N
WILSON	90-02-5113
WILSON NEW	90-02-5113, 90-02-5113N

Product Description

The ATG10165 alternator is a 12V, 105A aftermarket replacement designed for compatible Ford Mustang models equipped with the 4.6L V8 engine. It cross-references Ford part numbers XR3U-10300-AA, XR3U-10300-AB, XR3U-10300-AC, and XR3Z-10346-AA, along with multiple aftermarket references, including Lester 8252 and Arrowhead 400-14040.

This alternator features clockwise (CW) rotation, an internal regulator (IR), an internal fan (IF), and a 10 o’clock clock position. It is configured for a six-groove pulley with an outside diameter of approximately 51 mm, corresponding to pulley class 2271. These specifications should be matched against the original unit to ensure proper installation and belt alignment.

Designed for compatible 1999–2004 Ford Mustang applications, the ATG10165 provides an aftermarket replacement option for the vehicle's charging system. Confirm the original part number, pulley dimensions, mounting points, and electrical connections before ordering.

Product Specs

Item Condition	Aftermarket Part
Unit Type	Alternator
Voltage	12
Rotation	CW
Amperage	105
Clock	10
Pulley Class	2271
Regulator	IR
Fan Type	IF
Fits	FORD MUSTANG 1999-04 6-GROOVE PULLEY 51mm OD

Compatible Applications

MAKE	TYPE	MODEL	YEAR	ENGINE
FORD	Auto and Light Truck	MUSTANG	1999	4.6L(281) V8
FORD	Auto and Light Truck	MUSTANG	2000	4.6L(281) V8
FORD	Auto and Light Truck	MUSTANG	2001	4.6L(281) V8
FORD	Auto and Light Truck	MUSTANG	2002	4.6L(281) V8
FORD	Auto and Light Truck	MUSTANG	2003	4.6L(281) V8
FORD	Auto and Light Truck	MUSTANG	2004	4.6L(281) V8

Packaging Information

Item	Details
Net Weight	Estimated 5.5 kg
Gross Weight	Estimated 6.0 kg
Package Dimensions	To be confirmed
Packaging	Protective packaging for shipment

PRODUCT HIGHLIGHTS

Product Highlights

Feature	Description	Benefit
Charging Output	12V, 105A	Supports the charging requirements of compatible vehicle electrical systems
Integrated Design	Internal regulator and internal fan	Provides regulated charging and integrated cooling
Pulley Compatibility	Six-groove pulley, approximately 51 mm OD	Helps maintain proper belt alignment when matched to the original unit
