ATG11503 Alternator For Ford F-450 Super Duty 2011-2013 104210-6220 400-52403R

3 Reviews

Add Your Review

ITEMNO： ATG11503

OUT OF STOCK

Good Packaging

Safe Payment

100k+ Customers Top Choice

1 Year Warranty

90-Day Return

24/7 Service

Product Details Product Highlights Shipping

PRODUCT DETAILS

Arrowhead	AND0568
Denso	104210-6220, 104210-6221, 210-0830, ND210-0830
Ford	BC3T10300BA, BC3T10300DA, BC3Z10346A, BC3Z10346D, GL8754, GL992
J&N Electrical Products	400-52403
Jannco	400-52469R
Lester	11627

Product Specs

Item Condition	Aftermarket Part
Description	Alternator
Family	Denso SC (Hairpin)
Volt	12
Amps	215
Condition	Remanufactured
Regulator Clock	10:00
Rotation Direction	Clockwise
Mount Hole ID 1	10.400mm
Mount Hole 1 Type	Unthreaded
Mount Hole ID 2	M10x1.50
Mount Hole 2 Type	Threaded
Mount Hole ID 3	11.400mm
Mount Hole 3 Type	Unthreaded
Mounting Ear Thickness	0.598"
Mounting Ear Thickness	15.200mm
Mounting Ear 2 Thickness	0.909"
Mounting Ear 2 Thickness	23.100mm
Mounting Ear 3 Thickness	0.598"
Mounting Ear 3 Thickness	15.200mm
Fan Location	Internal
Regulator Location	Internal
Terminal ID 2	B+
Terminal 2 Size	M8x1.25
Terminal ID 3	LI
Terminal 3 Size	Spade
Terminal ID 4	RC
Terminal 4 Size	Spade
Terminal ID 5	AS
Terminal 5 Size	Spade
Polarity	Negative
Number Of Grooves	8
Groove OD	2.457"
Groove OD	62.400mm
Pulley Type	SolID
Pulley Outer Diameter	2.744"
Pulley Outer Diameter	69.700mm
Warranty	1 Year

MAKE	TYPE	MODEL	YEAR	ENGINE
Ford		F-250 Super Duty	6651cc, 6.7L/406CI V8	2011, 2012, 2013
Ford		F-250 Super Duty	6651cc, 6.7L/406CI V8	2011, 2012, 2013
Ford		F-250 Super Duty	6651cc, 6.7L/406CI V8 Diesel , DIESEL	2011
Ford		F-250 Super Duty	6651cc, 6.7L/406CI V8 Diesel , DIESEL	2012, 2013, 2014
Ford		F-250 Super Duty	6651cc, 6.7L/406CI V8 Diesel Turbocharged , DIESEL	2011, 2012, 2013
Ford		F-250 Super Duty	6651cc, 6.7L/406CI V8 Diesel Turbocharged , DIESEL	2011, 2012, 2013
Ford		F-250 SUPER-DUTY	6.7L(406) V8 Diese	2011, 2012, 2013, 2014
Ford		F-250	6700cc, 6.7L/409CI V8 Diesel , DIESEL	2011
Ford		F-350 Super Duty	6651cc, 6.7L/406CI V8	2011, 2012, 2013
Ford		F-350 Super Duty	6651cc, 6.7L/406CI V8	2011, 2013
Ford		F-350 Super Duty	6651cc, 6.7L/406CI V8	2012
Ford		F-350 Super Duty	6651cc, 6.7L/406CI V8 Diesel , DIESEL	2011
Ford		F-350 Super Duty	6651cc, 6.7L/406CI V8 Diesel Turbocharged , DIESEL	2011, 2012, 2013
Ford		F-350 Super Duty	6651cc, 6.7L/406CI V8 Diesel Turbocharged , DIESEL	2011, 2012, 2013
Ford		F-350 SUPER-DUTY	6.7L(406) V8 Diese	2011, 2012, 2013, 2014
Ford		F-450 Super Duty	6651cc, 6.7L/406CI V8	2011, 2012, 2013
Ford		F-450 Super Duty	6651cc, 6.7L/406CI V8	2011, 2012, 2013
Ford		F-450 Super Duty	6651cc, 6.7L/406CI V8 Diesel , DIESEL	2011
Ford		F-450 Super Duty	6651cc, 6.7L/406CI V8 Diesel Turbocharged , DIESEL	2011, 2012, 2013
Ford		F-450 Super Duty	6651cc, 6.7L/406CI V8 Diesel Turbocharged , DIESEL	2011, 2012, 2013
Ford		F-450 SUPER-DUTY	6.7L(406) V8 Diese	2011, 2012, 2013, 2014
Ford		F-450	6700cc, 6.7L/409CI V8 Diesel , DIESEL	2011
Ford		F-550 Super Duty	6651cc, 6.7L/406CI V8	2011, 2012, 2013
Ford		F-550 Super Duty	6651cc, 6.7L/406CI V8	2011, 2012, 2013
Ford		F-550 Super Duty	6651cc, 6.7L/406CI V8 Diesel , DIESEL	2011
Ford		F-550 Super Duty	6651cc, 6.7L/406CI V8 Diesel Turbocharged , DIESEL	2011, 2012, 2013
Ford		F-550 Super Duty	6651cc, 6.7L/406CI V8 Diesel Turbocharged , DIESEL	2011, 2012, 2013
Ford		F-550 SUPER-DUTY	6.7L(406) V8 Diese	2011, 2012, 2013, 2014
Ford		F-550	6700cc, 6.7L/409CI V8 Diesel , DIESEL	2011
Ford		F650	6700cc, 6.7L/408CI L6 Diesel , DIESEL	2011
Ford		F750	6700cc, 6.7L/408CI L6 Diesel , DIESEL	2011
Ford		F-Series	6651cc, 6.7L/406CI V8	2011, 2012, 2013
Ford		F-Series	6651cc, 6.7L/406CI V8 Diesel , DIESEL	2011, 2012, 2013, 2014
Ford		F-Series	6651cc, 6.7L/406CI V8 Diesel Turbocharged , DIESEL	2011, 2012, 2013
Ford		F-Series	6700cc, 6.7L/409CI V8 Diesel , DIESEL	2011
