ATG12474 Alternator 400-12765 10463043 1-1635-31DR for Chevrolet Beretta Cavalier – 12V 100A

3 Reviews

Add Your Review

US$128.00

ITEMNO： ATG12474

IN STOCK
BUY NOW ADD TO CART

Good Packaging

Safe Payment

100k+ Customers Top Choice

1 Year Warranty

90-Day Return

24/7 Service

TAGS：

Product Details Product Highlights Shipping

  • PRODUCT DETAILS

    ATG12474 Alternator 400-12765 10463043 1-1635-31DR for Chevrolet Beretta Cavalier – 12V 100A

    Part Numbers

    AC DELCO321-337, 321-405, 321-467, 321-574, 334-2334, 334-2366
    ARROWHEADADR0159, 400-12765
    CARGO110503
    DELCO10463043, 10463114, 10463175, 10463264, 10479963, 1101191, 1101461, 1101605, 1105701
    DELPHIRM1182
    LESTER7886-11, 7933-11
    LESTER (OLD)8126-11
    NSAALT-1310C
    REGITAR-USAA240-5159N
    WAI1-1635-31DR, 1-1636-31DR, 1-1636-32DR

    Product Description

    The ATG12474 Alternator is a high-quality aftermarket replacement designed for compatible General Motors passenger cars and light trucks. This 12V alternator delivers 100 amps of charging output and features clockwise (CW) rotation, an internal regulator (IR), and an external fan (EF). It uses a five-groove pulley with an approximately 62 mm outside diameter and a Delco CS130-style configuration with an 11 o'clock plug position.

    This alternator is intended for compatible Buick and Chevrolet applications, including the Buick Skyhawk and Chevrolet Beretta. Its charging capacity is designed to support the vehicle's electrical system when the alternator specifications and vehicle application match the original unit.

    The ATG12474 cross-references Arrowhead 400-12765, Delco 10463043, multiple AC Delco numbers, Lester references, and WAI replacement numbers. Before ordering, compare the original alternator's part number, connector orientation, pulley dimensions, amperage, and mounting configuration to ensure proper compatibility.

    Product Specs

    Item ConditionAftermarket Part
    Unit TypeAlternator
    Part TypeUNIT
    Voltage12
    RotationCW
    Amperage100
    Pulley Class1259
    RegulatorIR
    Fan TypeEF
    FitsGM CARS 1987-89
    DELCO CS130 11:00 PLUG
    5-GROOVE PULLEY 62mm OD



    MAKETYPE MODEL YEAR ENGINE
    BUICKAuto and Light TruckSKYHAWK19872.0L(122) L4
    CHEVROLETAuto and Light TruckBERETTA19872.0L(122) L4
    CHEVROLETAuto and Light TruckBERETTA19882.0L(122) L4
    CHEVROLETAuto and Light TruckBERETTA19892.0L(122) L4
    CHEVROLETAuto and Light TruckBERETTA19902.2L(134) L4
    CHEVROLETAuto and Light TruckBERETTA19912.2L(134) L4
    CHEVROLETAuto and Light TruckBERETTA19922.2L(134) L4
    CHEVROLETAuto and Light TruckCAVALIER19872.0L(122) L4
    CHEVROLETAuto and Light TruckCAVALIER19882.0L(122) L4
    CHEVROLETAuto and Light TruckCAVALIER19892.0L(122) L4
    CHEVROLETAuto and Light TruckCORSICA19872.0L(122) L4
    CHEVROLETAuto and Light TruckCORSICA19882.0L(122) L4
    CHEVROLETAuto and Light TruckCORSICA19892.0L(122) L4
    CHEVROLETAuto and Light TruckCORSICA19902.2L(134) L4
    CHEVROLETAuto and Light TruckCORSICA19912.2L(134) L4
    CHEVROLETAuto and Light TruckCORSICA19922.2L(134) L4
    OLDSMOBILEAuto and Light TruckFIRENZA19872.0L(122) L4
    OLDSMOBILEAuto and Light TruckFIRENZA19882.0L(122) L4
    PONTIACAuto and Light TruckTEMPEST19872.0L(122) L4
    PONTIACAuto and Light TruckTEMPEST19882.0L(122) L4
    PONTIACAuto and Light TruckTEMPEST19892.0L(122) L4
    PONTIACAuto and Light TruckTEMPEST19902.2L(134) L4
    PONTIACAuto and Light TruckTEMPEST19912.2L(134) L4

    Packaging Information

    ItemDetails
    Product1 × Alternator
    Estimated Net Weight5.5 kg
    Estimated Gross Weight6.4 kg
    Estimated Package Dimensions25 × 22 × 20 cm
    PackagingProtective carton with cushioning material


  • PRODUCT HIGHLIGHTS

    Highlights

    FeatureDescriptionBenefit
    100A Charging OutputDelivers 100 amps at 12VSupports charging and electrical power needs in compatible vehicles
    Internal RegulatorIncludes an internal voltage regulatorSimplifies replacement when matching the original alternator design
    Five-Groove PulleyUses a 5-groove pulley with approximately 62 mm outside diameterSupports correct belt alignment when matched to the original configuration
