ATG13205 Alternator 400-16141 3512058C91 ZLN4860J ZLN4860JB 4860J 4860JB A0014860JB for International Navistar Trucks and Buses – Detailed Description

Product Description

The ATG13205 Alternator is a high-quality aftermarket 12V, 200A alternator designed for selected International Navistar medium-duty, heavy-duty, and severe-service trucks and buses. Featuring an internal regulator, external fan, and clockwise (CW) rotation, this alternator provides reliable charging performance for demanding commercial vehicle applications.

This alternator is designed as a replacement for compatible units associated with Arrowhead 400-16141, International Harvester 3512058C91, ZLN4860J, ZLN4860JB, Leece Neville 4860J, 4860JB, A0014860JB, A0014860JBH, J&N 400-16013, Lester 8320, Mack 2MJ54, and WAI 1-2653-00LN.

With its 200-amp output, this alternator supports the electrical charging requirements of compatible International/Navistar vehicles equipped with engines from International Harvester (IHC), Caterpillar, Cummins, and Detroit Diesel. It is suitable for selected applications in the International 3000–3900, 4000–4900, 5000–5900, 7100–7700, 8100–8600, and 9100–9900 series.

Please verify the original alternator part number, voltage, amperage, mounting configuration, electrical connections, and pulley specifications before ordering. Fitment may vary by model year and engine configuration.

Product Specifications

• Product Type: Alternator

• Part Number: ATG13205

• Condition: Aftermarket Part

• Voltage: 12V

• Amperage: 200A

• Rotation: Clockwise (CW)

• Regulator Type: Internal Regulator (IR)

• Fan Type: External Fan (EF)

• Unit Type: Unit

• Weight: 11.5 kg

• Application: Selected International/Navistar Trucks and Buses

Interchange Part Numbers

• Arrowhead: ALN0015, 400-16141, PL4860JB

• International Harvester: 3512058C91, ZLN4860J, ZLN4860JB

• J&N Electrical Products: 400-16013

• Leece Neville: 4860J, 4860JB, A0014860JB, A0014860JBH

• Lester: 8320

• Mack: 2MJ54

• WAI: 1-2653-00LN

Vehicle Applications

This alternator fits selected applications in the following International/Navistar truck and bus series, depending on model year and engine configuration:

• International 3000–3900 Series Buses: 1997–2007

• International 4000–4900 Series Medium-Duty Trucks: 1997–2003

• International 5000–5900 Series Severe-Service Trucks: 1997–2003

• International 7100–7700 Series Severe-Service Trucks: 1997–2004

• International 8100–8600 Series Heavy-Duty Trucks: 1997–2003

• International 9100–9900 Series Heavy-Duty Trucks: 1997–2003
