STG52055 Starter Motor 0-001-368-024 for Mercedes-Benz Truck | 24V 4.0KW 9T CW DD Replacement-Products-TIANGUAN-Page 1

Home Products

STG52055 Starter Motor 0-001-368-024 for Mercedes-Benz Truck | 24V 4.0KW 9T CW DD Replacement

3 Reviews

Add Your Review

US$168.00

ITEMNO： STG52055

IN STOCK

BUY NOW ADD TO CART

Good Packaging

Safe Payment

100k+ Customers Top Choice

1 Year Warranty

90-Day Return

24/7 Service

TAGS：

Product Details Product Highlights Shipping

PRODUCT DETAILS

STG52055 Starter Motor 0-001-368-024 for Mercedes-Benz Truck | 24V 4.0KW 9T CW DD Replacement

OEM / Reference Part Numbers:
MERCEDES-BENZ: 003-151-04-01 / 003-151-74-01 / 003-151-86-01 / 003-151-88-01 / 004-151-59-01 / 004-151-73-01
BOSCH: 0-001-368-024 / 0-001-368-055 / 0-001-368-309 / 0-001-360-011 / 0-001-360-022 / 0-001-360-037 / 0-001-360-048 / 0-001-368-048 / 0-001-368-062 / 0-001-368-300 / 0-001-368-307
ARROWHEAD: SBO0064 / IS0407 / MS191
LESTER: 18371
LETRIKA: IS0407
PERKINS: 2873D301

Product Description

STG52055 Starter Motor is a heavy-duty aftermarket replacement for Mercedes-Benz commercial trucks and selected heavy-duty applications. The supplied SBO0064 cross-reference corresponds to the Bosch 368-series starter family.

This starter is rated at 24V and 4.0KW, with a 9-tooth pinion and Direct Drive (DD) configuration. The reference specifications identify CW (Clockwise) rotation.

Product Specifications

Property	Value
Product Model	STG52055
Bosch Part Numbers	0-001-368-024 / 0-001-368-055 / 0-001-368-309
Mercedes-Benz Part Number	003-151-04-01
Voltage	24V
Power Output	4.0KW
Starter Type	DD (Direct Drive)
Rotation	CW
Teeth Count	9T
Gear OD	34.3 mm
Mounting Hole Diameter	10.5 mm
Application	Mercedes-Benz Commercial Truck
Condition	New Aftermarket

OEM / Cross Reference Table

ARROWHEAD	SBO0064, MS191, IS0407, IS1296
BOSCH	0-001-360-011, 0-001-360-022, 0-001-360-037, 0-001-368-024, 0-001-368-048, 0-001-368-055, 0-001-368-062, 0-001-368-300, 0-001-368-307, 0-001-368-309
CARGO	110524
J & N	410-24177, 410-24384
LESTER	18371
LETRIKA (ISKRA) AFTERMARKET	IS 0407, IS 1296
LETRIKA (ISKRA) DESCRIPTION	AZF4151, AZJ0501, AZJ3113, AZJ3549, AZJ3589
LETRIKA (ISKRA) OEM	11.130.010, 11.130.230, 11.130.339, 11.130.407, 11.131.593
LIEBHERR	560-25-65
MAHLE	MS191
MERCEDES BENZ	003-151-04-01, 003-151-74-01, 003-151-86-01, 003-151-88-01, 004-151-59-01
PERKINS	2873D301
WILSON (OLD)	91-15-6924

Compatible Applications

MAKE	TYPE	MODEL	YEAR	ENGINE
Mercedes-Benz	LK1324L		1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001
Mercedes-Benz	U1000		1991, 1992
Mercedes-Benz	U1200		1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006
Mercedes-Benz	U1200T		1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001
Perkins		Various Models	6.354 T TBX TBZ 5791c	1985, 1986, 1987, 1988, 1989

Weight & Package Information

Item	Value
Net Weight	8.7 KG
Gross Weight	9.7 KG
Package Size	40 × 28 × 28 CM

PRODUCT HIGHLIGHTS

Product Highlights

Feature 1	Feature 2	Feature 3
Mercedes-Benz Truck Replacement	24V 4.0KW High-Torque Starter	9T CW Direct Drive
Bosch 0-001-368-024 Compatible	Heavy-Duty Commercial Vehicle Design	SBO0064 Replacement
003-151-04-01 Compatible	Durable Starting Performance	Direct-Fit Aftermarket Replacement
